| MODEL CODE |
GXR77UU |
| e-Brochure |
[] |
| Drive System |
4×2 |
| ENGINE |
|
| Model |
6UZ1-TCC |
| Type |
6-Cylinder In-line, 4-Cycle, Water-Cooled, OHC, Turbocharger with Intercooler |
| Displacement |
cc |
9,839 |
| Bore x Stroke |
mm |
120 x 145 |
| Compression Ratio |
17.5:1 |
| Maximum Output (Gross) |
kW (PS) @ rpm |
265 (360)@2,000 |
| Maximum Torque |
Nm (kgfm) @ rpm |
1422 (145)@1,400 |
| Emission Level |
Euro 3 |
| Fuel System |
Common Rail Direct Injection |
| TRANSMISSION |
|
| Model / No. of Speed |
ZF9S1310, 9 Speed Manual |
| Gear Ratio |
C |
9.479 |
| 1st |
6.576 |
| 2nd |
4.678 |
| 3rd |
3.478 |
| 4th |
2.617 |
| 5th |
1.890 |
| 6th |
1.345 |
| 7th |
1.000 |
| 8th |
0.752 |
| Reverse |
8.967 |
| Final |
5.429 |
| WEIGHT & CAPACITIES |
|
| Gross Vehicle Weight |
kg |
19,000 |
| Gross Combine Vehicle Weight |
kg |
39,000 |
| Curb Weight |
kg |
6,063 |
| Front |
kg |
4,008 |
| Rear |
kg |
2,055 |
| Fuel Tank Capacity |
l |
400 (Aluminium Alloy) |
| AXLE |
|
| Front |
Type |
Reverse Elliot, I-Beam |
| Front Axle Capacity (Design) |
kg |
7,500 |
| Rear |
Type |
Banjo, Full Floating |
| Rear Axle Capacity (Design 1) |
kg |
13,000 |
| Rear Axle Capacity (Design 2) |
kg |
– |
| Rear Axle Capacity (Design 1 + 2) |
kg |
13,000 |
| Rear Axle Capacity (Design) |
kg |
19,000 |
| SUSPENSION SYSTEM |
|
| Suspension |
Front |
Semi Elliptical Alloy Steel Leaf Springs Hydraulic Double Acting Telescopic Shock Absorber |
| Rear |
Semi Elliptical Alloy Steel Leaf Springs Hydraulic Double Acting Telescopic Shock Absorber |
| TYRES & WHEELS |
|
| Tyres |
295 / 80R22.5 |
| Wheels |
22.5 x 8.25 (ISO 10 Studs) |
| BRAKES |
|
| Service |
Full Air with Anti-Lock Braking System (ABS), Auto Adjuster |
| Parking Brake Type |
Spring Acting, Rear Wheel Parking |
| Auxiliary |
Exhaust Brake |
| STEERING |
|
| Steering System |
Power Assisted, Hydraulic Integral, Recirculating Ball, Energy Absorbing, Tilt & Telescopic Column |
| Min. Turning Radius |
m |
6.3 |
| ELECTRICAL |
|
| Battery |
12V x 2 |
| Alternator |
24V – 60A |
| DIMENSION |
|
| Overall Length |
OAL mm |
5,991 |
| Overall Width |
OAW mm |
2,490 |
| Overall Height |
OAH mm |
2,989 |
| Wheelbase |
WB mm |
3,480 |
| Front Overhang |
FOH mm |
1,480 |
| Rear Overhang |
ROH mm |
1,031 |
| Front Tread |
AW mm |
2,065 |
| Rear Tread |
CW mm |
1,850 |
