Performance

Useful Features

•

  New digital meter with enhanced visibilty on important information

•

  *Small turning radius for easy maneuvering in congested and tight areas

•

  *Sturdier leaf spring for better driving comfort with heavy loads, and with less deflection

•

  *Wide chassis frame 850mm

Interior

•

  Best-in-class spacious and quiet cabin with ergonomically designed and placed interior panels positioned for improved visibility makes driving more comfortable with ample room for 3 adults

•

  Audio and air-cond units

•

  Air suspension driver’s seat

•

  Brand New Feature – USB Charging Port

Safety

•

  Halogen reflectors provide outstanding illumination over a broad area to improve night time visibility and safety

•

  Anti-Lock Braking System (ABS)

•

  Six outer mirrors offer excellent all-round visibility of surroundings and minimizing blind-spots

•

  Rear fog lamp and reverse sensor

•

  Door impact beam with high tensile strength reinforcement frame

•

  Energy absorbing steering wheel and column

•

  SRS airbag system and seat belt with pretensioner areactivated in the event of a frontal collision, mitigatingimpact to the head and chest.

•

  Cabin Tilt Warning & Buzzer for driver safety warning

•

  LED Headlight to provide better visibility

•

  Headlight leveling. Preferred headlight beam position can be maintained when truck is loaded and when it has no load

Body Application

Specification

MODEL CODE		FSR90SU-QC
e-Brochure		[]
Drive System		4×2
ENGINE
Model		4HK1-TCS
SUSPENSION SYSTEM
Type		4-Cylinder Inline,4 Cycle Water-Cooled
		OHC, Variable Geometry System (VGS) Turbocharger with intercooler
Displacement	cc	5,193
Maximum Output (Gross)	kW (PS) @ rpm	154(210) @ 2600
Maximum Torque	Nm (kgfm) @ rpm	706 @ 1,600
Emission Level		Euro 4
Fuel System		Common Rail Direct Injection
After Treatment Exhaust Gas		DOC (Diesel Oxidation Catalyst)
TRANSMISSION
Model / No. of Speed		ISUZU MZW-6P/ 6-Speed MT
Gear Ratio	1st	6.615
	2nd	4.095
	3rd	2.358
	4th	1.531
	5th	1.000
	6th	0.722
	Reverse	6.615
	Final	6.143
WEIGHT & CAPACITIES
Gross Vehicle Weight	kg	13,500
Curb Weight	kg	3,900
Front	kg	2,435
Rear	kg	1,465
Fuel Tank Capacity	l	200
AXLE
Front	Type	Reverse Elliot, I-Beam
Front Axle Capacity (Design)	kg	5000
Rear	Type	Banjo, Full Floating
Rear Axle Capacity (Design)	kg	9,000
SUSPENSION SYSTEM
Suspension	Front	Semi Elliptical Alloy Steel Leaf Spring with Double Acting Telescopic Shock Absorber
	Rear	Semi Elliptical Alloy Steel Leaf Spring
TYRES & WHEELS
Tyres		265/70R19.5
Wheels		19.5X6.75
BRAKES
Service		Air Over Hydraulic Dual Circuit Front and Rear Drum Brakes
Parking Brake Type		Spring Park Brake Acting On All Rear Wheels
Auxiliary		Exhaust Brake
STEERING
Steering System		Power Assist, Hydraulic Integral Recirculating Ball Type
Min. Turning Radius	m	9.7
ELECTRICAL
Battery		65D26LX2
Alternator		24V-60A
DIMENSION
Overall Length	OAL mm	9,155
Overall Width	OAW mm	2,200
Overall Height	OAH mm	2,535
Wheelbase	WB mm	5,560
Front Overhang	FOH mm	1,170
Rear Overhang	ROH mm	2,425
Front Tread	AW mm	1805
Rear Tread	CW mm	1,705
